Techcal characteristics
|
ZL-200DL |
|
|
( Packaging speed ) |
20-100包/分钟 (20-100bags/min (depending on the package weight) ) |
|
( Measuring range ) |
10-500ml
(10-500ml(screw metering is customized according to customer requirements)) |
|
（Roll film diameter） |
≤200mm
≤ 200mm (customizable according to actual conditions)) |
| （BAG SIZE） | 长:MAX50-300m，宽90-200mm ( LengthMax: 50-300 width:90-200MM) |
| （SEALING TYPE） |
( back sealing bag, four-sided sealing bag, ironing bag, sawtooth bag) |
|
（Power specifications） |
220V/50Hz/2.35KW |
|
（Mechanical weight） |
380KG ( about 380KG) |
| （Machine quality） | 1431*962*1335MM ( Length: 1431width:962 height:1335 MM) |
