Specifications
| （Model） | |
| ( Bag size) | W:100-300mmL:100-500mm |
| ( Filling range) | 10-1000g |
| ( Packing speed) | 20-60包/分( Package/min)(速度由产品自身及充填重量决定)
( The speed isdetermined by the product itself and the filling weight) |
| ( Metering average accuracy) | ≤±1% |
| （Tota| power） | 1.5KW 380V 50HZ |
| (pension) | 1990*1409531m( Length*width*height） |
| ( Machine weight) | 1300KG |
| ( work process) |
( Baggingprinting production date-bag opening-filling 1-filling 2-heat sealing 1heat sealing 2-shaping and output) |
|
( Main standardomponents） |
(1. Coding machine2. PLC control system3.Bagopening device 4. Vibration device
5. Air cylinder 6. Temperaturecontroller 7. Vacuum pump 8 Frequency converter 9. Output system) |
| ( Packaging Materials） | BOPP/ CPPPET/AL/PE
( Heatable composite materials suchas bopp/CPP, Pet/AL/Pe, etc.) |
| ( Application) |
(1.BuIkmaterials 2. Granules 3. Powders 4. Liquid/sauce body 5. Pickles) |
| ( Option device） |
( Coding, inflation, exhaust,pinholes, hanging holes, labeling etc.) |
